Application:
This Automatic Noodle With Seasoning Sauce Sachet Flow Packing Machine, It is suitable for stacking packaging or secondary packaging of various block products. Such as noodles, chowmein, instant noodles, maggi noodles, vermicelli, stick noodles, bread, wafers, etc.
Kindly Reminder:
We have an experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Packing Exambers:
1. Feeding 5-10 pcs small sachets with flexible quantity as requested by hand.
2. Full servo drive with touch screen wrapping the small sachets, easy operation, wrapping stable with easy maintenance.
3. With arranging machine, arranging the products for cartons packaging.
| Model | LP-350 | LP-400 | LP-450 | LP-600 | LP-700 |
| Film Width | Max.350mm | Max.400mm | Max.450mm | Max.600mm | Max.700mm |
| Bag Length | 65-330mm | 150-400mm | 150-450mm | 160-500mm | 180-600mm |
| Bag Width | 50-160mm | 50-180mm | 50-180mm | 100-280mm | 100-330mm |
| Products High | Max.60mm | Max.65mm | Max.75mm | Max.110mm | Max.110mm |
| Film Roll Diameter | Max.320mm | Max.320mm | Max.320mm | Max.320mm | Max.320mm |
| Packing Speed | 40-180bag/min | 30-150bag/min | 30-150bag/min | 20-150bag/min | 20-130bag/min |
| Power | 220V 50/60Hz | 220V 50/60Hz | 220V 50/60Hz | 220V 50/60Hz | 220V 50/60Hz |
| 2.6KW | 2.8KW | 2.8KW | 2.8KW | 2.8KW | |
| Machine Size (L*W*H)mm | 4030*770*1420 | 4030*770*1420 | 4030*820*1420 | 4030*970*1500 | 4030*1070*1500 |
| Machine Weight | About 580kg | About 600kg | About 650kg | About 680kg | About 720kg |
| Optional Devices | 1.Lateral feed device, 2.Straight feed device, 3.Belt material conveyor, 4.End sealing auxiliary conveyor, 5.Auxiliary material feeding device, 6.Materia cut prevent device, 7.Perforating device, 8.Angle folding device, 9.Date Printer, 10.Labelling machine | ||||
After receiving your inquiry,We will send you the quotation as soon as possible.
