Application:
Suitable for automatic counting and packing machine for screws, nails, bolts, nuts, gaskets, bearings, glass parts, plastic parts, furniture accessories, toy accessories, blind nuts, gaskets, hardware, and plastic parts, etc.
Kindly Reminder:
We have an experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Packing Exambers:
1. Efficient: Bag-making, filling, sealing, cutting, heating, date/lot number achieved in one time.
2. Intelligent: Packing speed and bag length can be set through the screen without part changes.
3. Profession: Independent temperature controller with heat balance enables different packing materials.
4. Characteristic: Automatic stop function, with safe operation and saving of the film.
5. Convenient: Low loss, labor saving, easy for operation and maintenance.
6. Weighing accuracy 0.4 to 1.0 grams.
7. Hardware customized vibration plate packaging.
8. Nail count packaging.
9. Customize a variety of material mixing schemes.
| Model | LD-420 | LD-520 | LD-720 | LD-900 |
| Film width | Max.420mm | Max.520mm | Max.720mm | Max.900mm |
| Bag length | 80-300mm | 80-350mm | 100-500mm | 100-600mm |
| Bag width | 60-200mm | 100-250mm | 180-350mm | 260-430mm |
| Film roll diameter | Max.320mm | Max.320mm | Max.320mm | 400mm |
| Packaging rate | 5-60 bags/min | 5-60 bags/min | 5-55 bags/min | 5-20 bags/min |
| Range of measurement | 150-1500ml | 2000ml | 4000ml | 1-25L |
| Film thickness | 0.04-0.08mm | 0.04-0.12mm | 0.04-0.12mm | 0.04-0.12mm |
| Power | 220V, 50/60Hz, 2kw | 220V, 50/60Hz, 3kw | 220V, 50/60Hz, 3kw | 220V, 50/60Hz, 4.5kw |
| Machine size(LxWxH) | 1217*1015*1343mm | 1488*1080*1490mm | 1780*1350*2050mm | 2305*1685*2725mm |
| Machine quality | About 650kg | About 680kg | About 750kg |
After receiving your inquiry,We will send you the quotation as soon as possible.
