Automatic Volumetric Piston Bottling Honey Filling Capping Machine

  • Application
  • Description
  • Parameter
  • Video


It suits for different viscosity of water agent, semi-fluid and paste, it is widely used in the  product filling  of  foodstuff, cosmetics, medicine, grease, daily chemical industry, detergent, pesticide and chemical industry .

Packaging Material:

Glass, Metal, Paper, Plastic, Wood, Other

Kindly Reminder:

We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.

Packaging Exambers:应用图.jpg

1. Suitable material: Oil, jams, daily chemicals, and something that very viscous.

2.PLC control :This filling machine is a high-tech filling equipment controlled by microcomputer PLC programmable, equip with photo electricity transduction and pneumatic action.

3. Accurate measurement: adopt servo control system, ensure the piston can always reaches constant position.

4. Anti drop function :When close to target filling capacity can be applied to realize speed slow filling, prevent the liquid spill bottle mouth cause pollution.

5. Convenient adjustment: replacement filling specifications only in touch screen can be changed in parameters, and all filling first change in position, fine-tuning dose it in touch screen adjustment.

Heads of filling6
Production capacity(1L)≤20-40pcs/min
Flat bottles(mm)20-250ml,50-500ml,100-1000ml
Measure precision±1%
Compressed air pressure0.6-0.8Mpa
Motor power2.5KW
Overall dimension (L*W*H)4000*1350*2100
RemarkWe supply customized service

After receiving your inquiry,We will send you the quotation as soon as possible.
