Application:
Suitable to use in packing high accuracy and easily fragile material. Such as dried fruit, apple slices, nuts, pet food, puffy food, chips, jelly, candy, pistachio nuts, frozen dumplings, coffee beans, pasta, cotton candy, french fries, rice, small hardware, etc.
Sutable Pouch: Doypack, Box Pouch, Zipper Pouch, Stand Up Pouch, Stand Up Pouch With Hole, Kraft Paper Bag, Side Gusset Bag etc.
Kindly Reminder:
We have an experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Packing Exambers:
1. Automatic feeding product, Speed adjustable.
2. High speed and precision multi heads weigher dosing system.
3. Famous electric parts oversea, Top quality.
4. Customized station can adjust for flat bottom bag and doypack bag.
5. Twice sealing, make the bag more beautiful.
Workflow:
1. Z type elevator
2.10 Head High Precision Weigher with Teflon Coating
3. Horizontal feeding bag conveyor
4. Ribbon coding
5. Opening zipper and bag fully
6. Automatic filling→Nitrogen
7. Sealing-Output
| Type | LDSP-210A |
| Bag Type | 3-side, 4-side sealing bag, stand-up bag, handbag, spout bag, zipper bag, compound bag, etc. |
| Bag Size | W: 100-210 mm |
| Filling Range | 20-1000g |
| Packing Speed | 20-50 bags/min (speed is determined by the product filling quantity) |
| Average precision | ≤ ±1% |
| Total Power | 2.5KW |
| Weight | 900 KG |
| Main standard parts | 1. Code printer 2. PLC control system 3. Bag opening device 4. Vibration device 5. Cylinder 6. Electromagnetic valve 7. Temperaturecontroller 8. Vacuum pump 9. Inverter 10. Output system |
After receiving your inquiry,We will send you the quotation as soon as possible.
